Chapter 11: Magnum Router Cable Specifications
___________________________________________________________________
Female
DB25
Female
V.35
M5000C/FRAD
P
R
C
B
E
D
F
V
T
Y
S
AA
X
H
Transmit Data A (TD A)
Receive Data A (RD A)
Request To Send (RTS)
Clear To Send (CTS)
Data Set Ready (DSR)
Ground
Data Carrier Detect (DCD)
Serial Clock Receive External B (SCRE B)
Serial Clock Transmit External B (SCTE B)
Transmit Data B (TD B)
Serial Clock Transmit External A (SCTE A)
Receive Data B (RD B)
Serial Clock Receive External A (SCRE A)
Data Terminal Ready (DTR)
Shield
Request To Send (RTS)
Clear To Send (CTS)
Data Set Ready (DSR)
Ground
Data Terminal Ready (DTR)
Receive Line Signal Detector (RLSD)
Send Data (SD)
Send Data (SD)
Receive Data (RD)
Receive Data (RD)
Serial Clock Receive (SCR)
Serial Clock Receive (SCR)
Serial Clock Transmit (SCT)
Serial Clock Transmit (SCT)
Shield
APPLICATION: Magnum Router WAN1,2,3 Port to locally
attached FRAD (Frame Relay Access Device)
To Magnum To FRAD
1
2
3
4
5
6
7
8
9
12
14
20
17
16
15
11-4
