Chapter 6: Logging Onto a Magnum Router
___________________________________________________________________
6-5
Console Login
The default for logging onto a Magnum Router is a serial connection from the PC that is running
the Magnum Router Manager software to a Magnum Router card. The connection is
accomplished by connecting either the supplied DB-9 to DB-25 straight thru cable (or
equivalent) from the PC to the Magnum.
The settings for serial communication with a Magnum Router is 9600 Baud, 8 bits, No Parity
and 1 stop bit (commonly referred to as 9600,n,8,1) and cannot be changed.
As can be seen in the above screen, Console is already selected as the Login Method. Click
on the C
onnect button to begin the login process.
