3–45Configuring the Printer
Table 3–3. IGP/PGL Configuration Mode Options
NOTE: Parameters marked with an asterisk (*) indicate the factory default
value. The printer must be off-line to enter the configuration
structure.
Option Parameter
Value
Comments
AutoEject DISABLE *
ENABLE
If
the last page of a job is only 1/2 full (the data does not fill
the entire page), you can instruct the printer to eject the
page or leave it in the printer. ENABLE causes the printer
to eject the last page after the entire page has been
processed and printed. DISABLE instructs the printer to
eject the page only if you send a Page Eject command or
when the printer receives the next print job.
Auto Wrap DISABLE *
ENABLE
Controls
automatic “wrapping” of text
to the next line down
when the text exceeds the right margin.
DISABLE
truncates text beyond the
page margin until a CR
or
CR + LF is received. ENABLE automatically inserts a CR
+
LF after a full print line.
If a proportional spaced font is
used, this option is ignored
and the printer does not wrap text.
Define CR Code CR = CR *
CR = CR + LF
When CR = CR + LF, a line feed is automatically inserted
after each CR received, otherwise data passes through
unchanged.
Define LF Code LF = LF *
LF = CR + LF
When
LF = CR + LF
, a CR is automatically inserted before
each
line feed is processed, otherwise data passes
through
unchanged.
Ext Execute Copy DISABLE*
ENABLE
If DISABLED, dynamic data, overlay data, etc. are not
allowed
if the optional Form Count parameter is specified as
part of the Execute command.
If ENABLED, dynamic data, overlay data, etc. are allowed
within a form in which the Form Count parameter is
specified in the Execute command. In this case, the exact
same form (with
identical dynamic data, etc.) is printed for
whatever the Form Count is. Also, each form is printed on
a separate page.
