SVP 450 PLUS - SVD 500 PLUS
25
ENGLISHENGLISH
ENGLISHENGLISH
ENGLISH
VIDEO SETUP
Y/C DELAY
WHITE BALANCE
COMB. FILTER
GAMMA ADJ.
ADAPTIVE BLACK
BLUE STRETCH
5.2 Batteries
Handling the remote control and batteries:
- Avoid exposing the remote control to heat and humidity
- When not using the remote control for a long period of
time, remove the batteries.
- Avoid using the RC 3000 remote control with the infrared
control and service light on for a long time as battery
life would then be reduced.
- Do not use new and old batteries together or batteries
of a different voltage or type.
- Handle the remote control with care.
- Use the remote control within its operating range (about
10 metres and a 30° angle)
Note:
The RC3000 remote control is powered by AA 1.5
V batteries
5.3 How the RC 3000 remote control
works
Some buttons of the RC3100 remote control having the
same icons of the RC3100 perform the same function, so
the description is not repeated. The following paragraphs
describe the functions of the RC3000 remote control.
5.4 Video setup
5.4.1 To change the Y/C delay.
5.4.2 To switch on/off the comb filter.
5.4.3 To setup the gamma adjustment.
5.4.4 To switch on/off the adaptive black.
5.4.5 To switch on/off the blue stretch.
5.4.1 To setup the Y/C delay, you must
enter the installation mode.
Press VID.S, the following menu will appear.
Use the arrow or to select the Y/C delay and press
ENTER to confirm, the following menu will appear:
Use the arrow or to change the Y/C delay value.
VIDEO SETUP
Y/C DELAY 00
The value is correct when you are displaying a video signal
with colour bars and they are not overlapping.
Upon pressing the EXIT button to return to the video setting
menu, the following message will appear:
VIDEO SETUP
STORE DATA ?
Y / C DELAY 12
Press ENTER to confirm the setting or the EXIT button to
exit. Press EXIT to return to the video setting menu.
9 V O L T
4
AA 1.5 V
batteries
RC 3000
BACK OF THE
REMOTE
CONTROL
1
9V battery
IEC6F22
