SVP 450 PLUS - SVD 500 PLUS
28
WHITE BALANCE
SET TO
SET TO
SET TO
SET TO
3200K
6500K
9300K
USER
STORED
3200K ADJ
BLACK XX XX XX
R G B
WHITE XX XX XX
STORE DATA ?
5.7 White balance
To select one of the set colour temperatures
(3200°K,6500°K, 9300°K, USER BANK) for the
projected images.
To select one of the colour temperatures, proceed as
follows: press the button
for a few seconds, the
following menu will appear:
FACTORY SET: if you select this item, the system will
utilize the preset manufacturer regulations.
Use the arrow to select a colour temperature to change
and press ENTER to confirm, the following menu will
appear:
Press R, G, B, to select the BLACK R, BLACK G or BLACK
B item.
Press Rsel, Gsel, Bsel, to select WHITE R, WHITE G or
WHITE B item. The selected item willbe highlighted.
Use the arrow or to change the value.
Upon pressing the EXIT button to return to the video menu,
the software wil ask you to store the new values with this
message:
Use the arrow or to select WHITE BALANCE and
press ENTER to confirm, the following menu will appear.
The arrow on the left of the window indicates the current
setup.
Use the arrow or to select a setting and press ENTER
to confirm.
The SET TO USER is an optional setup.
This adjustment must be carried out by a qualified
technician.
To change the colour temperature settings, you must
enter in the installation mode.
Press the button VID.S, the following menu will appear:
VIDEO SETUP
Y/C DELAY
WHITE BALANCE
COMB. FILTER
GAMMA ADJ.
ADAPTIVE BLACK
BLUE STRETCH
WHITE BALANCE
VIDEO MENU
NOISE RED
STD SELECTION
BLANKING
UPC MENU
TLV SYNC
Use the arrow or to select the WHITE BALANCE
adjustment and press ENTER to confirm, the following
menu will appear:
WHITE BALANCE
ADJ.
ADJ.
ADJ.
ADJ.
SET
3200K
6200K
9300K
USER
FACTORY
Press ENTER to confirm or EXIT to exit.
After having ended this procedure, the selected new colour
temperature value willbe indicated by the arrow on the left
of the window.
5.8 Memory manager
With this menu you can select, copy, move or delete a
memory bank containing all the projector adjustments
or to store new ones.
Each memory bank is described by:
1. a number
2. a name or label
3. an aspect ratio flag
4. a horizontal frequency
5. a vertical frequency.
