SVP 450 PLUS - SVD 500 PLUS
33
ENGLISHENGLISH
ENGLISHENGLISH
ENGLISH
POWER ON
STAND BY
SWITCH ON
OPTIONS MENU
INSTALL. TYPE
MEMORY MANAGER
OSD
POWER ON
VCR STABILITY
WORKING TIME
OPTIONS MENU
VCR STABILITY ON
DEFL CENT
H. = 62 V. = 50
- PICTURE -
RASTER
To switch on or off the VCR stability, you must enter
the installation mode.
Press the OPT button, vi apparirà the following menu:
5.12 Deflection
First of all you must enetr the installation mode.
Press DEF to enter the deflection adjustment mode. Now
you can carry out all the adjustments necessary to align
the green tube image to the screen centre.
Throughly read these instructions if you are not familiar
with these adjustments
5.12.1 Deflection centre
The horizontal control DEF CENT is a PHASE control
and it does not affect the inner test patterns.
This function allows to centre the output signal image as
to the raster: you gain access to this menu by means of
the DEF button.
Use the arrow or to select VCR STABILITY the
following menu will appear:
Use the arrow or to switch on or off this function.
Whenever VCR stability is on, the video projector will
decode a signal with anti-copy codification.
Press the EXIT button to return to the options menu.
5.11 Fine picture adjustments
This paragraph is very important to achieve a perfect
fine adjustment of the projector once it has been
installed.
Read the following pages carefully.
It is very important to synchronise the projector with the
most frequently used input signals. The settings of each
signal type must be stored in a memory bank.
Use the arrow to centre the raster on the screen.
Press ENTER or EXIT to change function.
Press ESC to exit.
5.12.2 Deflection linearity
This function allows to change the distance between
lines, until they are equally distant.
DEFL LIN
H. = 50
V. = 50
b
b
a a
