SVP 450 PLUS - SVD 500 PLUS
32
Done
OPTIONS MENU
OSD
INSTALL. TYPE
POWER ON
VCR STABILITY
MEMORIY MANAGER
WORKING TIME
INSTALL. TYPE
DESKTOP FRONT
DESKTOP REAR
CEILING FRONT
CEILING REAR
OPTIONS MENU
OSD
INSTALL. TYPE
POWER ON
VCR STABILITY
MEMORY MANAGER
WORKING TIME
OPTIONS MENU
INSTALL. TYPE
MEMORY MANAGER
OSD
POWER ON
VCR STABILITY
WORKING TIME
Press ENTER to delete the memory bank, the following
message will appear:
The cursor will return to the left of the menu.
If the memory bank you are deleting is the one in use, it
will be deleted and the first bank with the same input signal
frequency will be loaded.
5.9 Installation types
To select the type of installation.
To select the TYPE OF INSTALLATION, you must enter
the installation mode.
Press OPT, the following menu will appear:
Use the arrow or to select INSTALL. TYPE and press
ENTER to confirm.
Press OPT. The following menu will appear:
Use the arrow or to select OSD and press ENTER to
confirm, the following menu will appear:
Use the arrow or to select the type of installation.
Press the button ENTER to confirm.
The arrow on the left indicates the current type of
installation.
Press EXIT to return to the previous menu.
5.10 Options menu
To set the message parameters.
To set the power ON.
To switch on/off the VTR stability.
To switch on or off the On Screen Display, you must
enter the installation mode.
OSD
OSD ON
MES. TIME 05
Use the arrow or to select OSD and the arrows or
to switch on or off the messages. If OSD is off, no
messages will be displayed on the screen when you
change contrast, brightness, etc.
To change the displaying time.
Use the arrow or to select DURATION, and the arrow
or to change the displaying time for the messages
on the screen (in seconds).
Press the button EXIT to return to the previous menu.
To switch the projector on/off automatically or via re-
mote control.
It is possible to decide to leave the projector in a stand-by
condition or to switch it on, after a temporary power cut-off;
in order to do so, you must enter installation mode.
Press OPT, the following menu will appear:
Use the arrow or to select POWER ON and press
ENTER to confirm.
The arrow indicates the current selection.
