SVP 450 PLUS - SVD 500 PLUS
39
ENGLISHENGLISH
ENGLISHENGLISH
ENGLISH
7 DISPLAY PERFORMANCES
7.1 Flyback time
- Horizontal 5,4 µs tip.
- Vertical 500 µs tip.
- R,G,B band width: 20 MHz, -3dB typical.
- Standard video band width: 5.5 Mhz, -3dB typical
- Contrast range: more than 100:1
- Warm up time (suggested): 20 minutes
7.2 Sinchro
- Horizontal frequency range:15 at 16,3 Khz and from
30 to 38 Khz .
- The model SVP 42 HB performs only up-to 34 KHz.
- Vertical frequency range: 45 to 130Hz - automatic
hooking
7.3 The complete function remote
control RC 3000
Operating mode:
- 1.- wired (by means of the 8-m cable supplied)
- 2.- wireless (max operating distance: 10 m)
Functions:
All adjustments can be carried out by means of the remo-
te control, but access can be gained to the following ones
by means of a button:
- Power on/off.
- Video muting.
- Freeze.
- Format selection.
- R-G-B tube power off.
- VCR synch filter.
- Normalized parameters.
- Storable image adjustments.
- Picture adjustment
- Deflection adjustment (installation mode).
- Convergence adjustment (installation mode).
- Zone adjustment (installation mode).
- Video projector status info.
- Video input selections.
- Reset picture adjustment (installation mode).
- Back illumination by pressing a dedicated key.
- Without pressing any other key, the back illumination
lasts about 20 seconds.
- By pressing any other key, the illumination counter is
restarted.
Batteries:
- 4 1,5 Volt batteries, mod. UM4 E R03P
- 1 9 Volt battery, mod 6F22A 9V
7.4 User remote control RC 3100
Operating mode:
wireless (max operating distance:10m/30ft)
Functions:
All adjustments can be carried out by means of the remo-
te control, but access can be gained to the following ones
by means of a button:
- Power on/off.
- Freeze.
- Format selection.
- Video muting.
- VCR synch filter.
- Storable image adjustments.
- Normalized values recall
- Picture adjustment
- Video menu.
- Video projector status info.
- Video input selections.
- Options
7.5 Keyboard on the rear panel
Functions:
- Power on/off.
- Video input selection.
- Analogic picture adjustment.
- Info menu.
7.6 BNC RGB inputs
BNC connectors:
- Red input 0.7 Vpp, termination 75 Ohm
- Green input 0.7 Vpp, termination 75 Ohm
- Blue input 0.7 Vpp, termination 75 Ohm
Or:
- BNC R = Input Cr 0,7 Vpp 75
- BNC G = Input Y 1 Vpp 75
- BNC B = Input Cb 0,7 Vpp 75
7.7 Input synchro
H, H/V sync, 75 Ohm termination
a) Horizontal Sync. 0.3-5Vpp, positive or negative.
b) Vertical Sync: 0.3-5Vpp, positive or negative.
