SVP 450 PLUS - SVD 500 PLUS
26
5.4.2 To switch on/off the Comb filter, you
have to enter in installation mode.
Press VID.S the following menu will appear:
VIDEO SETUP
Y/C DELAY
WHITE BALANCE
COMB. FILTER
GAMMA ADJ.
ADAPTIVE BLACK
BLUE STRETCH
VIDEO SETUP
COMB FILTER ON
Use the arrow or to select the comb filter and press
ENTER to confirm. The following menu will appear:
Use the arrow or to switch ON/OFF.
The comb. filter increase the separation between
luminance and chrominance in order to avoid cross colour
effects.
Press EXIT to go to the previous menu.
5.4.3 To setup the GAMMA ADJ., you must
enter installation mode.
Press VID.S the following menu will appear:
VIDEO SETUP
Y/C DELAY
WHITE BALANCE
COMB. FILTER
GAMMA ADJ.
ADAPTIVE BLACK
BLUE STRETCH
VIDEO SETUP
GAMMA ADJ. 00
Use the arrow or to select the GAMMA adjustment
and press ENTER to confirm, the following menu will
appear:
Use the arrow or to select the desired GAMMA value.
The GAMMA adjustment allows to make the best grey
scale linearity, as the tubes have a different output level
at different input levels.
Press EXIT to return to the video setup menu.
5.4.4 To switch on/off the DYNAMIC
BLACK, you must enter the
installation mode.
Press VID.S the following menu will appear:
VIDEO SETUP
Y/C DELAY
WHITE BALANCE
COMB. FILTER
GAMMA ADJ.
ADAPTIVE BLACK
BLUE STRETCH
VIDEO SETUP
ADAPTIVE BLACK ON
Use the arrow or to select ADAPTIVE BLACK and
press ENTER to confirm, the following menu will appear:
Use the arrow or to switch on/off the ADAPTIVE
BLACK. Press EXIT to return to the video setup menu.
5.4.5 To switch on/off the BLUE
STRETCH, you must enter the
installation mode.
Press VID.S the following menu will appear:
VIDEO SETUP
Y/C DELAY
WHITE BALANCE
COMB. FILTER
GAMMA ADJ.
ADAPTIVE BLACK
BLUE STRETCH
Use the arrow or to select the BLUE STRETCH
function and press ENTER to confirm, the following menu
will appear:
VIDEO SETUP
BLUE STRETCH ON
Use the arrow or to switch on/off the BLUE
STRETCH. This function allows to change the blue CRT
output, in order to have the best quality for the images.
Press EXIT to return to the video setup menu.
