Saddle Stitch Finisher (MJ-1024)
Tray loading capacity of Saddle Stitch Finisher (MJ-1024)
(MJ-1024 with mixed paper not loaded)
Unit: mm (with allowable error of ±7 mm)
Values in parentheses: Number of sheets (80 g/m
2
)
Sort/Group/Staple is not available with A5-R, B5-R, ST-R.
•See P.105 “Available conditions for saddle stitching” for tray loading capacity of saddle stitch tray.
If copied paper remains on the receiving tray and the next copying job is performed, the loading capac-
ity is the same as that for mixed paper.
(MJ-1024 with mixed paper loaded)
Unit: mm (with allowable error of ±7 mm)
Values in parentheses: Number of sheets (80 g/m
2
)
Model name MJ-1024
Type Floor type (Console type)
Acceptable paper size A3, A3-Wide, A4, A4-R, A5-R, B4, B5, B5-R, FOLIO, LD, LG, LT, LT-R,
ST-R, COMP
Acceptable paper weight
64 - 209 g/m
2
Number of copies stapled
at a time
(Including 2 covers (64 -
209 g/m
2
))
Paper size
80 g/m
2
90 g/m
2
105 g/m
2
A4, B5, LT 50 sheets 30 sheets 30 sheets
A3, A4-R, B4, FOLIO, LD,
LG, LT-R, COMP
30 sheets 15 sheets 15 sheets
Stapling position Front, Rear, Double
Stitching capacity
(Including 2 covers (64 -
209 g/m
2
))
Paper size
80 g/m
2
90 g/m
2
105 g/m
2
A3, A4-R, B4, LD, LT-R 15 sheets 10 sheets 10 sheets
Power source Supplied from the equipment
Dimensions 649 mm (W) x 657 mm (D) x 1086 mm (H)
Weight Approx. 70 kg
Power consumption 170 W max.
Mode Non-Sort Sort/Group Staples loaded
Tray No. 1 2 1 2 1 2
A4, A5-R, B5, LT,
ST-R
147
(1000)
147
(1000)
Whichever of 147
mm, 1000 sheets or
30 copies is reached
first
Whichever of 147
mm, 1000 sheets or
30 copies is reached
first
A3, A4-R, B4, B5-R,
FOLIO, LD, LG, LT-
R, COMP
73.5
(500)
73.5
(500)
Whichever of 73.5
mm, 500 sheets or
30 copies is reached
first
Whichever of 73.5
mm, 500 sheets or
30 copies is reached
first
Mode Non-Sort Sort/Group Staples loaded
Tray No. 1 2 1 2 1 2
A3 and A4 73.5
(500)
73.5
(500)
Whichever of 73.5
mm, 500 sheets or
30 copies is reached
first
Whichever of 73.5
mm, 500 sheets or
30 copies is reached
first
B4 and B5
FOLIO and A4-R
LD and LT
LG and LT-R
