Watlow EZ-ZONE
®
PM Integrated Controller • 71 • Appendix
Controller
P M
6__
__ __ __
-
__
__ __
__
A
__ __
EZ-ZONE
®
Integrated Controller Models
Universal Sensor Input, configuration communications
TRU-TUNE+
®
Adaptive Tune, red-green 7-segment displays
Package Size
6
1⁄16 DIN
Primary Function
C
PID Controller
R
Ramp and Soak
S
Custom Firmware
Power Supply, Digital Input/Output
1
100 to 240VÅ (ac)
2
100 to 240VÅ (ac) plus 2 digital i/o points
3
12 to 40VÎ (dc) and 20 to 28VÅ (ac)
4
12 to 40VÎ (dc) and 20 to 28VÅ (ac), plus 2 digital i/o points
Output 1 and 2 Hardware Options
Output 1 Output 2
CA
Switched dc/open collector None
CH
Switched dc/open collector No-arc 15 A power control
CC
Switched dc/open collector Switched dc
CJ
Switched dc/open collector Mechanical relay 5 A, form A
CK
Switched dc/open collector Solid-state relay 0.5 A, form A
EA
Mechanical relay 5 A, form C None
EH
Mechanical relay 5 A, form C No-arc 15 A power control
EC
Mechanical relay 5 A, form C Switched dc
EJ
Mechanical relay 5 A, form C Mechanical relay 5 A, form A
EK
Mechanical relay 5 A, form C Solid-state relay 0.5 A, form A
FA
Universal process None
FC
Universal process Switched dc (cannot use variable time base)
FJ
Universal process Mechanical relay 5 A, form A (cannot use variable time base)
FK
Universal process Solid-state relay 0.5 A, form A (cannot use variable time base)
AK
None Solid-state relay 0.5 A, form A
KK
Solid-state relay 0.5 A, form A Solid-state relay 0.5 A, form A
KH
Solid-state relay 0.5 A, form A No-arc 15 A power control
Communications Options All options below include EIA-485 Standard Bus.
A
None
1
EIA 485 Modbus RTU
®
With options 2 or 3, order option AA for outputs 3 & 4.
2
Modbus RTU 232/485
3
EtherNet/IP™, Modbus TCP
Auxilliary Control Functions With Communications Options 2 to 6, option A must be ordered below.
A
None
R
Remote Set point input
T
Current Transformer Input (no Output 3 & 4 Option FA, FC, FJ or FK)
L
Integrated Limit Controller with universal input (outputs 3 & 4 Option CJ, EJ or AJ only)
Output 3 and 4 Hardware Options With Communications Options 2 or 3, option AA must be ordered below.
Output 3 Output 4
AA
None None
AJ
None Mechanical relay 5 A, form A
CA
Switched dc/open collector None
CC
Switched dc/open collector Switched dc
CJ
Switched dc/open collector Mechanical relay 5 A, form A
CK
Switched dc/open collector Solid-state relay 0.5 A, form A
EA
Mechanical relay 5 A, form C None
EC
Mechanical relay 5 A, form C Switched dc
EJ
Mechanical relay 5 A, form C Mechanical relay 5 A, form A
EK
Mechanical relay 5 A, form C Solid-state relay 0.5 A, form A
FA
Universal Process None
FC
Universal Process Switched dc (cannot use variable time base)
FJ
Universal Process Mechanical relay 5 A, form A (cannot use variable time base)
FK
Universal Process Solid-state relay 0.5 A, form A (cannot use variable time base)
AK
None Solid-state relay 0.5 A, form A
KK
Solid-state relay 0.5 A, form A Solid-state relay 0.5 A, form A
Future Options
Additional Options
AA
Standard EZ-ZONE
®
face plate
12
Class 1, div. 2 (not available with Integrated Limit Controller or mechanical relay outputs)
Ordering Information for Integrated Controller Models
Note: The model of controller that you have is one of many possible models in the EZ-ZONE
®
PM family of controllers. To view the others, visit
our website (http://www.watlow.com/literature/pti search.cfm) and type EZ-ZONE
®
into the Keyword field.
