030-300500 Rev. A 9 October 2006
User Guide
VersaLink™ Gateway (Model 327W)
5. HARDWARE FEATURES
5.1 LED Indicators
This section explains the LED States and Descriptions. LED indicators are used to verify the unit’s operation and
status.
LED States and Descriptions
LED State Description
Solid Green
Modem power is ON.
OFF
Modem power is OFF.
POWER
Solid Red
POST (Power On Self Test), Failure (not bootable) or Device
Malfunction. NOTE: The Power LED should be red no longer
than two seconds after the power on self test passes.
Solid Green
Powered device is connected to the associated port (includes
devices with wake-on LAN capability where slight voltage is
supplied to an Ethernet connection).
NOTE: When using the optional uplink port (E1), Ethernet LAN
connection is limited to E2, E3, and E4.
Flashing Green
10/100 Base-T LAN activity is present (traffic in either direction)
ETHERNET
(E1, E2, E3, E4)
OFF
Modem power is OFF, no cable or no powered device is
connected to the associated port.
Solid Green
Link Established.
Flashing Green
Wireless LAN activity is present (traffic in either direction).
WIRELESS
OFF
Modem power is OFF or No Link.
Solid Green
Good DSL sync.
Flashing Green
DSL attempting to sync.
DSL
OFF
Modem power is OFF.
Solid Green
Internet link established.
Flashing Green
IP connection established and IP Traffic is passing through
device (in either direction).
NOTE: If the IP or PPP session is dropped due to an idle timeout,
the light will remain solid green, if an ADSL connection is still
present.
If the session is dropped for any other reason, the light is turned
OFF. The light will turn red when it attempts to reconnect and
DHCP or PPP fails).
Solid Red
Device attempted to become IP connected and failed (no DHCP
response, no PPP response, PPP authentication failed, no IP
address from IPCP, etc.).
INTERNET
OFF
Modem power is OFF, Modem is in Bridge Mode, or the
connection is not present.
NOTE: Safe Boot is reflected when the Power and Internet LEDs are both Red and all other LEDs are off.
