PRODUCT DIFFERENCES/USER CONSIDERATIONS
5-10 XEROX DOCUPRINT 180 LASER PRINTING SYSTEM PRODUCT GUIDE
tray. Refer to the
Xerox DocuPrint 180 LPS Operator Guide
for
loading instructions.
Note: Paper sizes with differences exceeding +25 mm in either
dimension cannot stack in the same bin. Feed Auto must be used,
and manual collation of the job is required upon completion. Some
applications written for a 9700F printer using multiple sizes (e.g. 8 X
11 variable data merge with 8.5 X 11 forms) may not run on the
DocuPrint 180 LPS due to added capability for paper size checking
between feed trays and user defined paper size statements in the
JSL/FSL.
Comparing DocuPrint 180 LPS print job resolution
Since Xerox laser printing systems have different print resolution
capabilities, it is important to compare the print resolution
functionality of your Xerox DocuPrint 180 LPS and of the LPS the job
was created on. Table 5-9 illustrates the print resolution
functionalities of the Xerox LPS.
Note: 600 dpi jobs can be created and compiled on an LPS only if
600 dpi fonts are loaded. Likewise, 300 dpi jobs can be created and
compiled on an LPS only if 300 dpi fonts are loaded.
Table 5-9. Print resolution of print jobs created or printed on
LPS
Paper resolution
functionality
DP180
& 4635 4050 4650 4090 4850 9790 8790
Creates and prints
300 dpi jobs
* * ****
Creates 300 dpi
jobs but prints in
600 dpi
**
Creates and prints
600 dpi jobs
*
Creates but does
not print 600 dpi
* ****
