Configuring the Switch
3-96
3
Web – Click Port, Port Statistics. Select the required interface, and click Query. You
can also use the Refresh button at the bottom of the page to update the screen.
Fragments The total number of frames received that were less than 64 octets in length
(excluding framing bits, but including FCS octets) and had either an FCS
or alignment error.
64 Bytes Frames The total number of frames (including bad packets) received and
transmitted that were 64 octets in length (excluding framing bits but
including FCS octets).
65-127 Byte Frames
128-255 Byte Frames
256-511 Byte Frames
512-1023 Byte Frames
1024-1518 Byte Frames
1519-1536 Byte Frames
The total number of frames (including bad packets) received and
transmitted where the number of octets fall within the specified range
(excluding framing bits but including FCS octets).
Table 3-54. Displaying Port Statistics
Parameter Description
