Alcatel Mapping Adjacency Protocol (AMAP)
3-99
3
• Common – The port has detected an adjacent switch and periodically sends
“Hello” packets to determine that it is still present.
• Passive – A port enters this state if there is no response to a Discovery “hello”
packet. This is a receive-only state and no “Hello” packets are transmitted. If a
“Hello” packet is received from an adjacent switch, the port enters the Common
state and then transmits a “Hello” packet in reply.
Use the AMAP Global Configuration screen to enable/disable AMAP and configure
timeout parameters.
Web – Click Alcatel, AMAP, Settings. Select whether to enable AMAP, enter the
desired timeout intervals and click ‘Apply’.
Figure 3-56. AMAP Settings
CLI – This example enables AMAP, sets the discovery timer to 200 seconds and
displays the current AMAP settings.
Displaying AMAP Detected Devices
To display any AMAP detected devices on the network use the ‘Display’ page.
Console(config)#amap enable
Console(config)#amap discovery timer 200
Console(config)#exit
Console#sh amap
AMAP is currently enabled
AMAP Common Phase Timeout Interval (seconds) = 300
AMAP Discovery Phase Timeout Interval (seconds) = 200
Console#
