Configuring the Switch
3-8
3
Basic Configuration
Displaying System Information
You can easily identify the system by displaying the device name, location and
contact information.
Field Attributes
• System Name – Name assigned to the switch system.
• Object ID – MIB II object ID for switch’s network management subsystem.
• Location – Specifies the system location.
• Contact – Administrator responsible for the system.
• System Up Time – Length of time the management agent has been up.
These additional parameters are displayed for the CLI.
• MAC Address – The physical layer address for this switch.
• Web server – Shows if management access via HTTP is enabled.
• Web server port – Shows the TCP port number used by the web interface.
• Web secure server – Shows if management access via HTTPS is enabled.
• Web secure server port – Shows the TCP port used by the HTTPS interface.
• POST result – Shows results of the power-on self-test
IGMP Snooping 3-160
IGMP Configuration Enables multicast filtering; configures parameters for multicast
query
3-161
Multicast Router
Port Information
Displays the ports that are attached to a neighboring multicast
router for each VLAN ID
3-162
Static Multicast Router Port
Configuration
Assigns ports that are attached to a neighboring multicast router 3-163
IP Multicast Registration
Table
Displays all multicast groups active on this switch, including
multicast IP addresses and VLAN ID
3-164
IGMP Member Port Table Indicates multicast addresses associated with the selected
VLAN
3-165
DNS 3-166
General Configuration Enables DNS; configures domain name and domain list; and
specifies IP address of name servers for dynamic lookup
3-167
Static Host Table Configures static entries for domain name to address mapping 3-169
Cache Displays cache entries discovered by designated name servers 3-171
Table 3-4. Main Menu
Menu Description Page
