Configuring Event Logging
3-25
3
• RAM Level – Limits log messages saved to the switch’s temporary RAM memory
for all levels up to the specified level. For example, if level 7 is specified, all
messages from level 0 to level 7 will be logged to RAM. (Default: 6)
Web – Click System, Log, System Logs. Specify the System Log Status,
modify the
level of messages to be logged
to RAM and flash memory
, and then click Apply.
Figure 3-4. Enabling System Logging
CLI – Enable system logging and then specify the level of messages to be logged to
RAM and flash memory. Use the show logging command to display the current
settings.
Remote Logs Configuration
The Remote Logs page allows you to configure the logging of messages that are
sent to syslog servers. You can also limit the error messages sent to only those
messages below a specified level.
Command Attributes
• Remote Log Status – Enables/disables the logging of debug or error messages
to the remote logging process. (Default: Enabled)
• Logging Facility – Sets the facility type for remote logging of syslog messages.
There are eight facility types specified by values of 16 to 23. The facility type is
used by the syslog server to dispatch log messages to an appropriate service.
(Default: 23)
• Logging Trap – Limits log messages that are sent to the remote syslog server for
all levels up to the specified level. For example, if level 3 is specified, all messages
from level 0 to level 3 will be sent to the remote server. (Default: 3)
Console(config)#logging on 4-41
Console(config)#logging history ram 6 4-42
Console(config)#
Console#show logging flash 4-45
Syslog logging: Enabled
History logging in FLASH: level errors
Console#
