Configuring the Switch
3-18
3
If you download to a new file name, then select the new file from the drop-down box
for Startup Configuration File, and press Apply Changes. To use the new settings,
reboot the system via the System/Reset menu.
Figure 3-14. Setting the Start-up Configuration File
CLI – Enter the IP address of the TFTP server, specify the source file on the server,
set the startup file name on the switch, and then restart the switch.
If you download the startup configuration file under a new file name, you can set this
file as the startup file at a later time, and then restart the switch.
Console Port Settings
You can access the onboard configuration program by attaching a VT100
compatible device to the switch’s serial console port. Management access through
the console port is controlled by various parameters, including a password, timeouts,
and basic communication settings. These parameters can be configured via the
Web or CLI interface.
Command Attributes
• Login Timeout – Sets the interval that the system waits for a user to log into the
CLI. If a login attempt is not detected within the timeout interval, the connection is
terminated for the session. (Range: 0 - 300 seconds; Default: 0)
• Exec Timeout – Sets the interval that the system waits until user input is detected.
If user input is not detected within the timeout interval, the current session is
terminated. (Range: 0 - 65535 seconds; Default: 600 seconds)
Console#copy tftp startup-config 4-62
TFTP server ip address: 192.168.1.19
Source configuration file name: config-1
Startup configuration file name [] : startup
\Write to FLASH Programming.
-Write to FLASH finish.
Success.
Console#reload
Console#config
Console(config)#boot system config: startup-new 4-66
Console(config)#exit
Console#reload 4-22
