Command Line Interface
4-174
4
• Since end-nodes cannot cause forwarding loops, they can be passed through
the spanning tree state changes more quickly than allowed by standard
convergence time. Fast forwarding can achieve quicker convergence for
end-node workstations and servers, and also overcome other STA related
timeout problems. (Remember that fast forwarding should only be enabled for
ports connected to a LAN segment that is at the end of a bridged LAN or for
an end-node device.)
• This command is the same as spanning-tree edge-port, and is only included
for backward compatibility with earlier products. Note that this command may
be removed for future software versions.
Example
Related Commands
spanning-tree edge-port (4-172)
spanning-tree link-type
This command configures the link type for Rapid Spanning Tree and Multiple
Spanning Tree. Use the no form to restore the default.
Syntax
spanning-tree link-type {auto | point-to-point | shared}
no spanning-tree link-type
• auto - Automatically derived from the duplex mode setting.
• point-to-point - Point-to-point link.
• shared - Shared medium.
Default Setting
auto
Command Mode
Interface Configuration (Ethernet, Port Channel)
Command Usage
• Specify a point-to-point link if the interface can only be connected to exactly
one other bridge, or a shared link if it can be connected to two or more bridges.
• When automatic detection is selected, the switch derives the link type from the
duplex mode. A full-duplex interface is considered a point-to-point link, while
a half-duplex interface is assumed to be on a shared link.
• RSTP only works on point-to-point links between two bridges. If you designate
a port as a shared link, RSTP is forbidden. Since MSTP is an extension of
RSTP, this same restriction applies.
Console(config)#interface ethernet 1/5
Console(config-if)#bridge-group 1 portfast
Console(config-if)#
