Basic Configuration
3-17
3
CLI – Enter the IP address of the TFTP server, select “config” or “opcode” file type,
then enter the source and destination file names, set the new file to start up the
system, and then restart the switch.
Saving or Restoring Configuration Settings
You can upload/download configuration settings to/from a TFTP server. The
configuration file can be later downloaded to restore the switch’s settings.
Command Attributes
• TFTP Server IP Address – The IP address of a TFTP server.
•
File Name
— The configuration file name should not contain slashes (\ or /),
the
leading letter of the file name should not be a period (.), and the maximum length
for file names on the TFTP server is 127 characters or 31 characters for files on
the switch. (Valid characters: A-Z, a-z, 0-9, “.”, “-”, “_”)
Note:
The maximum number of user-defined configuration files is limited only by
available flash memory space.
Downloading Configuration Settings from a Server
You can download the configuration file under a new file name and then set it as the
startup file, or you can specify the current startup configuration file as the destination
file to directly replace it. Note that the file “Factory_Default_Config.cfg” can be
copied to the TFTP server, but cannot be used as the destination on the switch.
Web – Click System, File, Configuration. Enter the IP address of the TFTP server,
enter the name of the file to download, select a file on the switch to overwrite or
specify a new file name, and then click Transfer from Server.
Figure 3-13. Transfering a Configuration File from a Server
Console#copy tftp file 4-62
TFTP server ip address: 10.1.0.19
Choose file type:
1. config: 2. opcode: <1-2>: 2
Source file name: M100000.bix
Destination file name: V1.0
\Write to FLASH Programming.
-Write to FLASH finish.
Success.
Console#config
Console(config)#boot system opcode:V1.0 4-66
Console(config)#exit
Console#reload 4-22
