System Management Commands
4-29
4
Example
Web Server Commands
ip http port
This command specifies the TCP port number used by the Web browser interface.
Use the no form to use the default port.
Syntax
ip http port port-number
no ip http port
port-number - The TCP port to be used by the browser interface.
(Range: 1-65535)
Default Setting
80
Command Mode
Global Configuration
Console#show management all-client
Management Ip Filter
Http-Client:
Start ip address End ip address
-----------------------------------------------
1. 192.168.1.19 192.168.1.19
2. 192.168.1.25 192.168.1.30
Snmp-Client:
Start ip address End ip address
-----------------------------------------------
1. 192.168.1.19 192.168.1.19
2. 192.168.1.25 192.168.1.30
Telnet-Client:
Start ip address End ip address
-----------------------------------------------
1. 192.168.1.19 192.168.1.19
2. 192.168.1.25 192.168.1.30
Console#
Table 4-12. Web Server Commands
Command Function Mode Page
ip http port Specifies the port to be used by the Web browser interface GC 4-29
ip http server Allows the switch to be monitored or configured from a browser GC 4-30
ip http secure-server Enables HTTPS/SSL for encrypted communications GC 4-30
ip http secure-port Specifies the UDP port number for HTTPS/SSL GC 4-31
