Chapter 2 Printer Operation
Menu Setting Table
Page Setup Menu - allows you to change settings related to the media or print quality.
System Setup Menu - allows you to change settings for the printer hardware and basic control systems.
After Print Menu - changes how the printer reacts after the label has been printed.
Interfaces - changes interface parameters such as baud rate.
Option Interfaces - communication settings of Option Interfaces.
Machine Information, Test Mode - allows you to check and/or print test pages and information about the
printer.
Global Cong menu - allows you to switch between 3 complete ‘cong sets’ contained within the printer.
Press the MENU key in print possible status to enter MENU Setup Mode. Use the keys on the operation panel
according to the LCD display to setup the printer. The contents that can be setup on the printer are shown
below. And the items that are actually displayed on the LCD are shown in [ ].
For Datamax® Emulation
Top Menu Sub Menu Default Menu Remarks
Page Setup Print Speed 6 IPS 2 to 8 IPS Printing speed setting.
(7 or 8 IPS only in Direct Thermal mode.)
(2 to 6 IPS with optional peeler.)
Print Darkness 10 00 to 30 Adjusting print darkness.
Darkness Adjust
[Darkness Adj]
00 -10 to 10 Fine adjustment of darkness commands.
Print Method TT TT
DT
Selecting thermal transfer (ribbon) /direct
thermal media.
Continuous Media
Length
[Cont Media Len]
4.00 inch
101.6 mm
0.25 to 158.00 inch
6.4 to 4013.2 mm
Setting media length of continuous media.
Lower level = during mm mode.
Vertical Position
[Vertical Pos]
0.00 inch
0.0 mm
-1.00 to 1.00 inch
-25.4 to 25.4 mm
Adjusting printing start position.
Horizontal Position
[Horizontal Pos]
0.00 inch
0.0 mm
-1.00 to 1.00 inch
-25.4 to 25.4 mm
Adjusting horizontal image position.
Vertical Image Shift
[Vertical Image]
0.00 inch
0.0 mm
0.00 to 32.00 inch
0.0 to 812.8 mm
Adjust the o set value in vertical when
mapping data on a RAM.
Auto Side Shift 00 dot 00 to 15 dots Allows horizontal shifting of printing
position by specied number of dots per
page.
Eective when load is applied to a specic
head area, like vertical lines.
Media Sensor See Through See Through
Reect
Non
Selecting media sensor.
Small Media
Adjustment
[Small Media Adj]
O On
O
Setting for small media
Small Media Length
[Small Media Len]
1.00 inch
25.4 mm
0.25 to 1.00 inch
6.4 to 25.4 mm
Setting media length for small media.
Symbol Set PM 50 symbols Setting symbol set.
Mode Settings
