47
Chapter 2 Printer Operation
For Zebra® Emulation
Top Menu Sub Menu Default Menu Remarks
Page Setup
Print Speed 6 IPS 2 to 8 IPS Printing speed setting.
(7 or 8 IPS only in Direct Thermal mode.)
(2 to 6 IPS with optional peeler.)
Print Darkness 10 00 to 30 Adjusting print darkness.
Darkness Adjust
[Darkness Adj]
00 -10 to 10 Fine adjustment of darkness commands.
Print Method TT TT
DT
Selecting thermal transfer (ribbon) /direct
thermal media.
Continuous Media
Length
[Cont Media Len]
4.00 inch
101.6 mm
0.25 to 158.00 inch
6.4 to 4013.2 mm
Setting media length of continuous media.
Lower level = during mm mode.
Vertical Position
[Vertical Pos]
0.00 inch
0.0 mm
-1.00 to 1.00 inch
-25.4 to 25.4 mm
Adjusting printing start position.
Horizontal Position
[Horizontal Pos]
0.00 inch
0.0 mm
-1.00 to 1.00 inch
-25.4 to 25.4 mm
Adjusting horizontal image position.
Vertical Image Shift
[Vertical Image]
000 dots -120 to 120 dots Adjust the o set value in vertical when
mapping data on a RAM.
Auto Side Shift 00 dot 00 to 15 dots
Allows horizontal shifting of printing position
by specied number of dots per page.
Eective when load is applied to a specic
head area, like vertical lines.
Media Sensor See Through See Through
Reect
Non
Selecting media sensor.
Small Media
Adjustment
[Small Media Adj]
O On
O
Setting for small media
Small Media Length
[Small Media Len]
1.00 inch
25.4 mm
0.25 to 1.00 inch
6.4 to 25.4 mm
Setting media length for small media.
Symbol Set PM 50 symbols Setting symbol set.
System Setup
Sensor Monitor
– –
Displays level of sensor that is currently selected.
Sensor Level
1.7V 0.0V to 3.3V Selects threshold of the sensor.
Paper End Level
3.00V 0.01 to 3.30V Sets the paper end level.
Error Reporting
[Error Report]
On Printing On Printing
Immediate
Setting for error report.
Buzzer Select Exec/Err Exec/Err
All
Error
Key
None
Setting buzzer sounding conditions.
Metric/Inch
[Metric/Inch Sel]
Inch Inch
mm
Sets the units.
Max Media Length
[Max Media Len]
10.00 inch
254.0 mm
1.00 to 158.00 inch
25. 4 to 4013.2 mm
Sets the maximum media length.
Settings Lock O On
O
Prevents a command changing the set
value.
Mode Settings
