45
Chapter 2 Printer Operation
Top Menu Sub Menu Default Menu Remarks
Network Address ** – 000.000.000.000 to
255.255.255.255
Setting xed IP address of the LAN board.
Subnet Mask ** – 000.000.000.000 to
255.255.255.255
Setting xed subnet mask value of the LAN
board.
Gateway Address ** – 000.000.000.000 to
255.255.255.255
Setting xed default gateway address of
the LAN board.
BOOTP ** – On
O
Setting the BOOTP of the LAN board.
DHCP ** – On
O
Setting the DHCP of the LAN board.
WLAN Mode *** – Auto
Ad-Hoc
Infrastructure
Wireless LAN mode setting.
WLAN Channel *** – 01 to 14 Wireless LAN channel setting.
WLAN SSID *** – Max. 32 characters SSID setting of Wireless LAN.
Machine
Information
[Machine Info]
Model Number – CL-E*** Displays the model name.
Boot Version – *.* Displays the boot version
ROM Version – ******** Displays the ROM version.
ROM Date – **/**/** Displays the date the ROM was prepared.
ROM CheckSum
– **** Displays the check sum of the ROM
FPGA Version – *.* Displays the FPGA version
Head Check – OK
NG
Displays the results of the head check.
Print Counter – ****.*** km Displays the print counter.
Service Counter
– ****.*** km Displays the service counter.
Cut Counter – ******* Displays the cut count.
Sensor Monitor – *.* V Displays the sensor level.
Option Interface
[Option I/F]
– None
RS-232C
LAN
IEEE1284
Displays the presence/absence of the
optional interface.
• If Dip Switch 1 is ON in RS-232C interface,
RS-232C (DIP SW) will be displayed. (See
“Interface” in the section of Appendix)
RS-232C Baud – – If Dip Switch 1 is ON in RS-232C interface,
the communication condition set in Dip
Switch will be displayed.
RS-232C Parity – –
RS-232C Length – –
RS-232C Stop bit – –
RS-232C X-ON – –
MAC Address – – Displays MAC Address
**
If the multi-function LAN board is mounted, or during web monitor function.
***When the multi-function wireless LAN board is available and when Web monitor is operating.
Note: Settings related to interface are enabled after restart or after power is connected again.
Mode Settings
[Datamax® Emulation]
