Chapter 2 Printer Operation
Top Menu Sub Menu Default Menu Remarks
Interfaces USB Device Class
[USB Device Clas]
Printer Printer
VCOM
Selects the USB device class.
USB VCOM Protocol
[VCOM Protocol]
Auto Auto
DTR
X-ON
Selects the protocol (ow control) when
operating USB VCOM.
USB 2.0 High Speed
[USB Hi Speed]
On On
O
Enable/disable setting of USB2.0 High
Speed.
When disabled, device runs at Full Speed.
IPv4 Address 169.254.001.010 000.000.000.000 to
255.255.255.255
Set of IPv4 Network Address
IPv4 Subnet Mask
[IPv4 Subnet]
255.255.000.000 000.000.000.000 to
255.255.255.255
Set IPv4 Subnet Mask
IPv4 Gateway 000.000.000.000 000.000.000.000 to
255.255.255.255
Set IPv4 Gateway
IPv4 DHCP On On
O
IPv4 DHCP enable/disable setting
IPv6 On On
O
IPv6 enable/disable setting
Option
Interfaces
RS-232C Baud 9600 115200
57600
38400
19200
9600
4800
2400
Setting the baud rate of the serial interface.
• All settings related to the interface are
enabled after the power is reconnected.
RS-232C Parity None None
Odd
Even
Setting the communication parity for the
serial interface
RS-232C Length 8 bits 8 bits
7 bits
Setting the character length for the serial
interface.
RS-232C Stopbit 1 bit 1 bit
2 bits
Setting the stop bit for the serial interface.
RS-232C X-ON Yes Yes
No
Selectively setting the X-ON ow control of
the serial interface.
IEEE1284 * On On
O
Setting both direction of the Centro
Interface.
Web Monitor * Auto Auto
On
O
Selecting the web monitor function.
*
If the parallel board or multi-function LAN board is mounted.
Note: Settings related to interface are enabled after restart or after power is connected again.
Mode Settings
[Datamax® Emulation]
