PECIFICATIONS
Chapter 14 - Specifications
Operating systems supported:
• Microsoft Windows XP
• Microsoft Windows 2000
Notebook computers supported:
• Please see the Digital Tigers Web site (http://digitaltigers.com) for certified notebooks
Notebook interface:
• CardBus PCMCIA PC Card (supplied)
• 1-meter interface cable (supplied)
Display types supported:
• Analog (VGA-type DB-15 connector)
• Digital (DVI-I connector; compatible with DVI-D connector)
• Total displays supported: Up to 4 (plus notebook display and notebook monitor port)
• Combination of displays supported:
o 4 analog; 4 digital; or any combination up to 4
Display modes supported* (per monitor)
Resolution Color depth
Max
Refresh
640 x 480 256 colors (8-bit), High color (16-bit), True color (24-bit), True color (32-bit) 85 Hz
800 x 600 256 colors (8-bit), High color (16-bit), True color (24-bit), True color (32-bit) 85 Hz
1024 x 768 256 colors (8-bit), High color (16-bit), True color (24-bit), True color (32-bit) 85 Hz
1152 x 864 256 colors (8-bit), High color (16-bit), True color (24-bit), True color (32-bit) 85 Hz
1280 x 1024 256 colors (8-bit), High color (16-bit), True color (24-bit), True color (32-bit) 85 Hz
1280 x 960 256 colors (8-bit), High color (16-bit), True color (24-bit), True color (32-bit) 85 Hz
1600 x 1200 256 colors (8-bit), High color (16-bit), True color (24-bit), True color (32-bit) 85 Hz
1600 x 1280 256 colors (8-bit), High color (16-bit), True color (24-bit), True color (32-bit) 60 Hz
1792 x 1344 256 colors (8-bit), High color (16-bit), True color (24-bit), True color (32-bit) 75 Hz
1800 x 1440 256 colors (8-bit), High color (16-bit), True color (24-bit), True color (32-bit) 70 Hz
1856 x1392 256 colors (8-bit), High color (16-bit), True color (24-bit), True color (32-bit) 75 Hz
1920 x 1080 256 colors (8-bit), High color (16-bit), True color (24-bit), True color (32-bit) 75 Hz
1920 x 1440 256 colors (8-bit), High color (16-bit), True color (24-bit), True color (32-bit) 75 Hz
2048 x 1536 256 colors (8-bit), High color (16-bit), True color (24-bit), True color (32-bit) 60 Hz
*Note: Support for any specific display mode is dependent on support for that mode by the
particular monitor. Exceeding the specifications of a monitor can damage the display. (For this
reason, Windows display drivers may exclude some choices from availability for your monitor.)
Resolution modes higher than 1280 x 1024 are for analog (VGA) displays only. Maximum
resolution for digital (DVI) monitors is 1280 x 1024 at true color (32-bit).
For fastest application responsiveness and performance, we recommend a maximum
resolution of 1280x1024 at 16-bit color for both analog and DVI monitors.
