APPLICATION FUNCTIONS 5-43
MON2000
JULY 2010 Streams
.
Only the base pressure can be edited. The
base temperature is a constant 6
o
F (15
o
C)
for all calculations.
4. To view or print the baseline run results,
click the button or press
the F2 key. The Baseline Values dialog
appears.
5. Click the button to return to the
main window.
Table 5-6 Description of GC Calculation Parameters
Par Setting Description
PSIA
BAR
base temperature in PSIA or bar units
deg F
deg C
base temperature in degrees Fahrenheit
or Celsius
Opt Pres 1
Opt Pres 2
Opt Pres 3
If compressibility is activated for a par-
ticular stream (Calculation Control
function, (see Section 5.5.1), up to 3
optional pressures can be defined to
calculate additional post-analysis data.
To change the displayed system
units, see Section 5.1 for details.
If a stream is not used,
you cannot access
baseline data for that
stream.
