Chapter 2 Operator Panel 53
Chapter 2
Drive Configuration
The Drive Config Menu lets you modify each drive’s configuration. Figure 18
on page 53 shows an example screen. For each drive, the menu displays:
■ Drive position
■ Drive type
■ If the drive path is SCSI, the drive’s SCSI ID and its SCSI bus relationship
with the library.
Sub-menus let you change the SCSI ID and configure whether the drive is on
the same SCSI bus as the library. For more information, see Drive Entries on
page 76.
Note The cursor position is saved on all screens that list the library’s
drives.
The panel displays 16 lines of data per menu. If your library
contains more than eight drives, you must use the down arrow
button to scroll to drives 08 and above.
Figure 18 Drive Configuration Menu
SET DRIVE SCSI ID MENU:
01 HP LTO ID: 02
VALID RANGE 0 - 15
SCROLL UP TO INCR
SCROLL DOWN TO DECR
SELECT TO SAVE
MENU TO EXIT
