88 Entering Configuration Data Chapter 3
Cleaning Cartridge Warning Count
Note For cleaning cartridge information specific to your drive type,
see Drives and Media on page 135.
After a predetermined count, a cleaning cartridge must be replaced.
Note The Auto Clean feature is automatically enabled if you insert
even one cleaning cartridge into the reserved cell area and then
reset the library.
If the Auto Clean feature is enabled, use the operator panel to set the
maximum number of times a cleaning cartridge can be used (see Table 5 on
page 88).
Note With 3.00 firmware and higher, an asterisk (*) may appear on
the operator panel display. For example, HP A5597A (Code
3.00.xx)*. The asterisk (*) denotes the cleaning cartridge’s life
has expired. To determine which cartridge has expired and to
eject the expired cartridge, see For cleaning cartridge
information specific to your drive type, see Drives and Media
on page 135. on page 88, and Exporting Data Cartridges
through the CAP on page 104.
Table 5
Cleaning Cartridge Warning Counts
Cleaning Cartridge Type
Cleaning Cartridge TypeCleaning Cartridge Type
Cleaning Cartridge Type
Recommended Warning Counts
Recommended Warning Counts Recommended Warning Counts
Recommended Warning Counts
(maximum)
(maximum)(maximum)
(maximum)
LP LTO Ultrium 15 uses
LP LTO Ultrium
(universal)
50 uses
DLT 8000 20 uses
9840 100 uses
