Intel® Xeon® Processor E5-1600 v2/E5-2600 v2 Product Families 181
Datasheet Volume One of Two
Processor Land Listing
VSS DD36 GND
VSS DD38 GND
VSS DD6 GND
VSS DE17 GND
VSS DE41 GND
VSS DE53 GND
VSS DE7 GND
VSS DF12 GND
VSS DF36 GND
VSS DF42 GND
VSS DF44 GND
VSS DF46 GND
VSS DF48 GND
VSS DF50 GND
VSS DF52 GND
VSS DF8 GND
VSS E1 GND
VSS E29 GND
VSS E3 GND
VSS E31 GND
VSS E41 GND
VSS E5 GND
VSS F36 GND
VSS F42 GND
VSS F44 GND
VSS F48 GND
VSS F50 GND
VSS F8 GND
VSS G1 GND
VSS G25 GND
VSS G31 GND
VSS G35 GND
VSS G37 GND
VSS G41 GND
VSS G45 GND
VSS G47 GND
VSS G5 GND
VSS G51 GND
VSS G53 GND
VSS G57 GND
VSS G9 GND
VSS H10 GND
Table 8-1. Land Name (Sheet 45 of 50)
Land Name Land No. Buffer Type Direction
VSS H12 GND
VSS H14 GND
VSS H32 GND
VSS H34 GND
VSS H38 GND
VSS H40 GND
VSS H52 GND
VSS H54 GND
VSS H8 GND
VSS J11 GND
VSS J27 GND
VSS J31 GND
VSS J33 GND
VSS J39 GND
VSS J41 GND
VSS J5 GND
VSS J55 GND
VSS K2 GND
VSS K26 GND
VSS K28 GND
VSS K30 GND
VSS K34 GND
VSS K8 GND
VSS L25 GND
VSS L29 GND
VSS L41 GND
VSS L5 GND
VSS M34 GND
VSS M36 GND
VSS M42 GND
VSS M44 GND
VSS M46 GND
VSS M50 GND
VSS M52 GND
VSS M8 GND
VSS N13 GND
VSS N33 GND
VSS N35 GND
VSS N37 GND
VSS N41 GND
VSS N43 GND
VSS N47 GND
Table 8-1. Land Name (Sheet 46 of 50)
Land Name Land No. Buffer Type Direction
