Intel® Xeon® Processor E5-1600 v2/E5-2600 v2 Product Families 183
Datasheet Volume One of Two
Processor Land Listing
8.2 Listing by Land Number
VTTD AT42 PWR
VTTD AY42 PWR
VTTD BD42 PWR
VTTD BH42 PWR
VTTD BK56 PWR
VTTD BL51 PWR
VTTD BM42 PWR
VTTD BR55 PWR
Table 8-1. Land Name (Sheet 49 of 50)
Land Name Land No. Buffer Type Direction
VTTD BU47 PWR
VTTD BV42 PWR
VTTD BY20 PWR
VTTD BY22 PWR
VTTD CA21 PWR
VTTD CA23 PWR
VTTD_SENSE BP42 O
Table 8-1. Land Name (Sheet 50 of 50)
Land Name Land No. Buffer Type Direction
Table 8-2. Land Number (Sheet 1 of 49)
Land No. Land Name Buffer Type Direction
A11 DDR3_DQ[33] SSTL I/O
A13 DDR3_MA[13] SSTL O
A15 DDR3_WE_N SSTL O
A17 DDR3_BA[0] SSTL O
A19 DDR3_MA[00] SSTL O
A21 DDR3_MA[05] SSTL O
A23 DDR3_MA[11] SSTL O
A33 DDR3_DQ[22] SSTL I/O
A35 DDR3_DQ[16] SSTL I/O
A37 DDR3_DQ[07] SSTL I/O
A39 DDR3_DQ[01] SSTL I/O
A41 VSS GND
A43 VSS GND
A45 VSS GND
A47 VSS GND
A49 VSS GND
A5 VSS GND
A51 VSS GND
A53 RSVD
A7 VSS GND
A9 DDR3_DQ[39] SSTL I/O
AA11 VSS GND
AA13 DDR2_DQ[37] SSTL I/O
AA15 DDR2_CS_N[3] SSTL O
AA17 DDR2_CS_N[9] SSTL O
AA19 DDR2_CS_N[4] SSTL O
AA21 DDR2_CLK_DP[2] SSTL O
AA23 DDR2_CLK_DP[3] SSTL O
AA25 DDR2_CKE[0] SSTL O
AA27 DDR2_ECC[7] SSTL I/O
AA29 VSS GND
AA3 VSS GND
AA31 VSS GND
AA33 DDR2_DQS_DN[03] SSTL I/O
AA35 DDR2_DQ[28] SSTL I/O
AA37 DDR2_DQ[10] SSTL I/O
AA39 VSS GND
AA41 DDR2_DQ[13] SSTL I/O
AA43 PE3D_TX_DN[14] PCIEX3 O
AA45 PE3D_TX_DP[12] PCIEX3 O
AA47 PE3C_TX_DP[9] PCIEX3 O
AA49 PE3A_RX_DP[3] PCIEX3 I
AA5 VSS GND
AA51 PE3B_RX_DP[7] PCIEX3 I
AA53 PE3B_RX_DP[6] PCIEX3 I
AA55 VSS GND
AA7 DDR2_DQS_DN[14] SSTL I/O
AA9 VSS GND
AB10 DDR2_DQ[38] SSTL I/O
AB12 DDR2_DQS_DP[13] SSTL I/O
AB14 VSS GND
AB16 DDR2_CS_N[6] SSTL O
AB18 DDR2_MA[00] SSTL O
AB20 DDR2_CS_N[0] SSTL O
AB22 DDR2_CLK_DP[1] SSTL O
AB24 DDR2_CLK_DP[0] SSTL O
Table 8-2. Land Number (Sheet 2 of 49)
Land No. Land Name Buffer Type Direction
