Intel® Xeon® Processor E5-1600 v2/E5-2600 v2 Product Families 193
Datasheet Volume One of Two
Processor Land Listing
C15 VCCD_23 PWR
C17 VCCD_23 PWR
C19 VCCD_23 PWR
C21 VCCD_23 PWR
C23 VCCD_23 PWR
C25 DDR3_ECC[3] SSTL I/O
C3 VSS GND
C33 VSS GND
C35 DDR3_DQ[21] SSTL I/O
C37 DDR3_DQ[02] SSTL I/O
C39 VSS GND
C41 VSS GND
C43 DMI_TX_DP[1] PCIEX O
C45 DMI_TX_DP[3] PCIEX O
C47 DMI_RX_DP[0] PCIEX I
C49 DMI_RX_DP[2] PCIEX I
C5 VSS GND
C51 PE1A_RX_DP[0] PCIEX3 I
C53 RSVD
C55 VSS GND
C7 DDR3_DQ[52] SSTL I/O
C9 DDR3_DQ[34] SSTL I/O
CA1 DDR0_DQ[12] SSTL I/O
CA11 VSS GND
CA13 VCCPLL PWR
CA15 VCCPLL PWR
CA17 DDR01_RCOMP[0] Analog I
CA19 VSS GND
CA21 VTTD PWR
CA23 VTTD PWR
CA25 VCC PWR
CA27 VSS GND
CA29 VCC PWR
CA3 DDR0_DQ[13] SSTL I/O
CA31 VSS GND
CA33 VSS GND
CA35 VSS GND
CA37 VSS GND
CA39 VSS GND
CA41 VSS GND
CA43 TDO ODCMOS O
CA45 RSVD
Table 8-2. Land Number (Sheet 21 of 49)
Land No. Land Name Buffer Type Direction
CA47 QPI0_DTX_DN[12] QPI O
CA49 QPI0_DTX_DN[13] QPI O
CA5 VSS GND
CA51 QPI0_DTX_DP[11] QPI O
CA53 VTTA PWR
CA55 VSS GND
CA57 VSS GND
CA7 DDR0_DQ[05] SSTL I/O
CA9 DDR0_DQ[29] SSTL I/O
CB10 DDR0_DQS_DP[12] SSTL I/O
CB12 DDR0_DQ[26] SSTL I/O
CB14 DDR0_ECC[4] SSTL I/O
CB16 VSS GND
CB18 DDR_RESET_C01_N CMOS1.5v O
CB2 DDR0_DQ[08] SSTL I/O
CB20 DDR01_RCOMP[2] Analog I
CB22 MEM_HOT_C01_N ODCMOS I/O
CB24 DDR0_ODT[4] SSTL O
CB26 DDR0_CS_N[6] SSTL O
CB28 DDR0_CS_N[3] SSTL O
CB30 DDR0_DQ[37] SSTL I/O
CB32 DDR0_DQS_DN[13] SSTL I/O
CB34 DDR0_DQ[39] SSTL I/O
CB36 VSS GND
CB38 DDR0_DQ[48] SSTL I/O
CB4 DDR0_DQ[09] SSTL I/O
CB40 DDR0_DQS_DN[06] SSTL I/O
CB42 DDR0_DQ[55] SSTL I/O
CB44 SVIDCLK ODCMOS O
CB46 VSS GND
CB48 VSS GND
CB50 VSS GND
CB52 VSS GND
CB54 ERROR_N[1] ODCMOS O
CB56 VSS GND
CB6 VSS GND
CB8 VSS GND
CC11 DDR0_DQS_DN[12] SSTL I/O
CC13 VSS GND
CC15 DDR0_ECC[1] SSTL I/O
CC17 DDR0_DQS_DP[08] SSTL I/O
CC19 DDR01_RCOMP[1] Analog I
Table 8-2. Land Number (Sheet 22 of 49)
Land No. Land Name Buffer Type Direction
