Intel® Xeon® Processor E5-1600 v2/E5-2600 v2 Product Families 187
Datasheet Volume One of Two
Processor Land Listing
AN47 PE3D_RX_DP[13] PCIEX3 I
AN49 PE2A_TX_DP[0] PCIEX3 O
AN5 VCC PWR
AN51 PE2A_TX_DP[2] PCIEX3 O
AN53 PE2B_TX_DP[6] PCIEX3 O
AN55 VSS GND
AN57 VSS GND
AN7 VCC PWR
AN9 VCC PWR
AP10 VCC PWR
AP12 VCC PWR
AP14 VCC PWR
AP16 VCC PWR
AP2 VCC PWR
AP4 VCC PWR
AP42 VSS GND
AP44 VSS GND
AP46 PE3D_RX_DN[14] PCIEX3 I
AP48 RSVD
AP50 PE2A_TX_DN[1] PCIEX3 O
AP52 PE2A_TX_DN[3] PCIEX3 O
AP54 PE2B_TX_DP[7] PCIEX3 O
AP56 PE2D_RX_DP[13] PCIEX3 I
AP58 VSS GND
AP6 VCC PWR
AP8 VCC PWR
AR1 VSS GND
AR11 VSS GND
AR13 VSS GND
AR15 VSS GND
AR17 VSS GND
AR3 VSS GND
AR43 BPM_N[0] ODCMOS I/O
AR45 PE3D_RX_DN[15] PCIEX3 I
AR47 PE3D_RX_DN[13] PCIEX3 I
AR49 PE2A_TX_DN[0] PCIEX3 O
AR5 VSS GND
AR51 PE2A_TX_DN[2] PCIEX3 O
AR53 PE2B_TX_DN[6] PCIEX3 O
AR55 RSVD
AR57 PE2C_RX_DP[11] PCIEX3 I
AR7 VSS GND
Table 8-2. Land Number (Sheet 9 of 49)
Land No. Land Name Buffer Type Direction
AR9 VSS GND
AT10 VSS GND
AT12 VSS GND
AT14 VSS GND
AT16 VSS GND
AT2 VSS GND
AT4 VSS GND
AT42 VTTD PWR
AT44 BPM_N[1] ODCMOS I/O
AT46 VSS GND
AT48 BIST_ENABLE CMOS I
AT50 FRMAGENT CMOS I
AT52 VSS GND
AT54 PE2B_TX_DN[7] PCIEX3 O
AT56 PE2D_RX_DN[13] PCIEX3 I
AT58 PE2D_RX_DP[12] PCIEX3 I
AT6 VSS GND
AT8 VSS GND
AU1 VCC PWR
AU11 VCC PWR
AU13 VCC PWR
AU15 VCC PWR
AU17 VCC PWR
AU3 VCC PWR
AU43 BPM_N[2] ODCMOS I/O
AU45 VSS GND
AU47 VSS GND
AU49 VSS GND
AU5 VCC PWR
AU51 VSS GND
AU53 VTTA PWR
AU55 RSVD
AU57 PE2C_RX_DN[11] PCIEX3 I
AU7 VCC PWR
AU9 VCC PWR
AV10 VCC PWR
AV12 VCC PWR
AV14 VCC PWR
AV16 VCC PWR
AV2 VCC PWR
AV4 VCC PWR
AV42 VSS GND
Table 8-2. Land Number (Sheet 10 of 49)
Land No. Land Name Buffer Type Direction
