Processor Land Listing
204 Intel® Xeon® Processor E5-1600 v2/E5-2600 v2 Product Families
Datasheet Volume One of Two
K6 DDR3_DQS_DP[06] SSTL I/O
K8 VSS GND
L1 DDR3_DQ[62] SSTL I/O
L11 DDR3_DQS_DN[05] SSTL I/O
L13 DDR3_DQ[41] SSTL I/O
L15 DRAM_PWR_OK_C23 CMOS1.5v I
L17 DDR2_BA[1] SSTL O
L19 DDR3_ODT[0] SSTL O
L21 DDR3_CLK_DP[1] SSTL O
L23 DDR3_CLK_DP[0] SSTL O
L25 VSS GND
L27 DDR3_DQ[27] SSTL I/O
L29 VSS GND
L3 DDR3_DQS_DN[07] SSTL I/O
L31 DDR3_DQ[25] SSTL I/O
L33 DDR3_DQ[28] SSTL I/O
L35 DDR3_DQ[10] SSTL I/O
L37 DDR3_DQS_DN[01] SSTL I/O
L39 DDR3_DQ[09] SSTL I/O
L41 VSS GND
L43 PE1A_TX_DN[1] PCIEX3 O
L45 PE1A_TX_DN[3] PCIEX3 O
L47 PE1B_TX_DN[5] PCIEX3 O
L49 PE1B_TX_DN[7] PCIEX3 O
L5 VSS GND
L51 PE3A_TX_DN[1] PCIEX3 O
L53 PE1B_RX_DN[4] PCIEX3 I
L55 PE2A_RX_DP[0] PCIEX3 I
L57 PE1B_RX_DN[6] PCIEX3 I
L7 DDR3_DQ[54] SSTL I/O
L9 DDR3_DQ[43] SSTL I/O
M10 DDR3_DQ[47] SSTL I/O
M12 DDR3_DQS_DN[14] SSTL I/O
M14 DDR3_DQ[45] SSTL I/O
M16 DDR3_ODT[5] SSTL O
M18 DDR2_MA_PAR SSTL O
M2 DDR3_DQ[63] SSTL I/O
M20 DDR3_CLK_DN[2] SSTL O
M22 DDR3_CLK_DP[3] SSTL O
M24 DDR3_CKE[1] SSTL O
M26 DDR3_DQ[31] SSTL I/O
M28 DDR3_DQ[26] SSTL I/O
Table 8-2. Land Number (Sheet 43 of 49)
Land No. Land Name Buffer Type Direction
M30 DDR3_DQS_DN[12] SSTL I/O
M32 DDR3_DQ[24] SSTL I/O
M34 VSS GND
M36 VSS GND
M38 DDR3_DQS_DP[10] SSTL I/O
M4 DDR3_DQS_DP[07] SSTL I/O
M40 DDR3_DQ[12] SSTL I/O
M42 VSS GND
M44 VSS GND
M46 VSS GND
M48 RSVD
M50 VSS GND
M52 VSS GND
M54 PE1B_RX_DN[5] PCIEX3 I
M56 PE1B_RX_DN[7] PCIEX3 I
M6 DDR3_DQ[55] SSTL I/O
M8 VSS GND
N11 DDR3_DQS_DP[05] SSTL I/O
N13 VSS GND
N15 VCCD_23 PWR
N17 VCCD_23 PWR
N19 VCCD_23 PWR
N21 VCCD_23 PWR
N23 VCCD_23 PWR
N25 DDR3_CKE[3] SSTL O
N27 DDR3_DQ[30] SSTL I/O
N29 DDR3_DQS_DP[03] SSTL I/O
N3 DDR3_DQ[58] SSTL I/O
N31 DDR3_DQS_DP[12] SSTL I/O
N33 VSS GND
N35 VSS GND
N37 VSS GND
N39 DDR3_DQ[08] SSTL I/O
N41 VSS GND
N43 VSS GND
N45 VSA PWR
N47 VSS GND
N49 VSS GND
N5 VSS GND
N51 VSA PWR
N53 VSS GND
N55 PE2A_RX_DN[0] PCIEX3 I
Table 8-2. Land Number (Sheet 44 of 49)
Land No. Land Name Buffer Type Direction
