Intel® Xeon® Processor E5-1600 v2/E5-2600 v2 Product Families 223
Datasheet Volume One of Two
Boxed Processor Specifications
Figure 10-7. Boxed Processor Motherboard Keepout Zones (4 of 4)
13
4
5678
B
C
D
A
123
4
5678
B
C
D
A
76.50
81.50
2200 MISSION COLLEGE BLVD.
R
P.O. BOX 58119
SANTA CLARA, CA 95052-8119
MIN97.0°
MIN97.0°
93.0
93.00
4.38
.03
G11950 4 B
DWG. NO SHT. REV
THIS DRAWING CONTAINS INTEL CORPORATION CONFIDENTIAL INFORMATION. IT IS DISCLOSED IN CONFIDENCE AND ITS CONTENTS
MAY NOT BE DISCLOSED, REPRODUCED, DISPLAYED OR MODIFIED, WITHOUT THE PRIOR WRITTEN CONSENT OF INTEL CORPORATION.
SHEET 4 OF 4
DO NOT SCALE DRAWING
SCALE: 1.500
PTMI
BG11950D
REV
DRAWING NUMBER
SIZE
DEPARTMENT
SECONDARY SIDE
3D HEIGHT RESTRICTION ZONES
PRIMARY SIDE
3D HEIGHT RESTRICTION ZONES
AND VOLUMETRIC SWEEPS OF LOADPLATE
AND LEVER OPENING/CLOSING
TOP SURFACE OF MOTHERBOARD
VOLUMETRIC SWEEPS FOR
LOADPLATE AND LEVERS
DURING OPENING AND CLOSING
