Intel® Server Boards S5000PSL and S5000XSL TPS Appendix B: BMC Sensor Tables
Sensor
Name
Sensor
Number
System
Applica-
bility
Sensor Type Event /
Reading
Type
Event Offset
Triggers
Criticality Assert /
De-assert
Readable
Value /
Offsets
Event Data Rearm Standby
Sparing OK
Fault status
asserted
Degraded
Device installed OK
Disabled Degraded
DIMM D1 E6h All Slot
Connector
21h
Sensor
Specific
6Fh
Sparing OK
As – Trig Offset A –
Fault status
asserted
Degraded
Device installed OK
Disabled Degraded
DIMM D2 E7h All Slot
Connector
21h
Sensor
Specific
6Fh
Sparing OK
As – Trig Offset A –
Memory A
Error
ECh All Memory
0Ch
Sensor
Specific
6Fh
Correctable
ECC
Uncorrectable
ECC
OK As – Trig Offset A –
Memory B
Error
EDh System-
specific
Memory
0Ch
Sensor
Specific
6Fh
Correctable
ECC
Uncorrectable
ECC
OK As – Trig Offset A –
Memory C
Error
EEh System-
specific
Memory
0Ch
Sensor
Specific
6Fh
Correctable
ECC
Uncorrectable
ECC
OK As – Trig Offset A –
Memory D
Error
EFh System-
specific
Memory
0Ch
Sensor
Specific
6Fh
Correctable
ECC
Uncorrectable
ECC
OK As – Trig Offset A –
B0 DIMM
Sparing
Enabled
F0h All Entity
Presence
25h
Sensor
Specific
6Fh
Entity present OK As – Trig Offset A –
B0 DIMM F1h All Memory Discrete Fully redundant OK As – Trig Offset A –
Revision 1.2
Intel order number: D41763-003
107
