Server Board Overview Intel® Server Boards S5000PSL and S5000XSL TPS
3.1.3.2 Supported Memory
The server board supports up to eight DDR2-533 or DDR2-667 fully-buffered DIMMs (FBD memory). The following tables show the
maximum memory configurations supported with the specified memory technology.
Table 4. Maximum Eight-DIMM System Memory Configruation – x8 Single Rank
DRAM Technology
x8 Single Rank
Maximum Capacity
Mirrored Mode
Maximum Capacity
Non-mirrored Mode
256 Mb 1 GB 2 GB
512 Mb 2 GB 4 GB
1024 Mb 4 GB 8 GB
2048 Mb 8 GB 16 GB
Table 5. Maximum Eight-DIMM System Memory Configuration – x4 Dual Rank
DRAM Technology
x4 Dual Rank
Maximum Capacity
Mirrored Mode
Maximum Capacity
Non-mirrored Mode
256 Mb 4 GB 8 GB
512 Mb 8 GB 16 GB
1024 Mb 16 GB 32 GB
2048 Mb 16 GB 32 GB
Note: Only fully buffered DDR2 DIMMs (FBDIMMs) are supported on this server board. See the Intel
®
Server Board
S5000PSL/S5000XSL Tested Memory List for a list of supported memory for this server board.
3.1.3.3 DIMM Population Rules and Supported DIMM Configurations
DIMM population rules depend on the operating mode of the memory controller, which is determined by the number of DIMMs
installed. DIMMs must be populated in pairs. DIMM pairs are populated in the following DIMM slot order: A1 & B1, C1 & D1, A2 &
B2, C2 & D2. DIMMs within a given pair must be identical with respect to size, speed, and organization. However, DIMM capacities
can be different between different DIMM pairs.
Revision 1.2
Intel order number: D41763-003
