Replacement Procedures
Satellite L20 Maintenance Manual(960-Q01) 159
Installing a HDD
The following describes the procedure for installing a HDD (See Figure 4-4 to 4-5).
1. Install a HDD to the HDD holder and secure it with the following screws.
• M3.0×3.5F FLAT BIND screw x4
NOTE: Although they are 3mm head screws, screw torque must be set in 2.5kg-cm for
four screws securing the HDD holder.
2. Insert the HDD assembly into the HDD slot and connect it carefully to the CN18 on
the system board.
3. Secure the HDD assembly with the following screw.
• M2.5×4.0B FLAT BIND screw x1
