Replacement Procedures
4
4.10 Display assembly
Removing the display assembly
The following describes the procedure for removing the display assembly (See Figure 4-15 to
4-20).
1. Close the display and turn the computer upside down .
2. Remove the following screws from the k/b cover of the computer.
• M2.0×3.0 FLAT BIND screw x2 (Locktight)
• M2.5×6.0 FLAT BIND screw x2 (Locktight)
M2.0x3.0 FLAT BIND
(Locktight)
M2.5x6.0 FLAT BIND
(Locktight)
Figure 4-12 Removing the screws (securing display assembly)
.
Satellite L20 Maintenance Manual(960-Q01) 175
