Board Layout
B-4 Satellite L10 Maintenance Manual(960-Q01)
Table B-2 System board ICs and connectors (back)
Mark Number Name
(a) CN10 DC Power Jack
(b) CN8 S-VIDEO OUT connector
(c) CN11 USB Connector
(d) CN2 Phone Signal Connector
(e) CN9 RJ11 + RJ45 Connector
(f) CN13 CRT Connector
(g) CN14 System Battery Connector
(h) CN15 CPU Fan Connector
(i) CN18 USB Connector
(j) U18 CPU Socket
(k) CN19 USB Connector
(l) CN20 External MIC Connector
(m) CN21 Headphone Out Connector
(n) CN24 Modem Board Connector
(o) CN16 HDD Connector
(p) J2 DDR SO-DIMM 0
(q) J1 DDR SO-DIMM 1
(r) CN22 ODD Connector
(s) CN25 MINI PCI Connector
