Replacement Procedures
180 Satellite L20 Maintenance Manual(960-Q01)
Installing the display assembly
The following describes the procedure for installing the display assembly (See Figure 4-15 to
4-20).
1. Inserting the pole of hinge to the hole of hinge assembly, set the display assembly
on the base assembly.
2. Secure the hinges with the following screws , Secure the display mask with the
following screws and stick the mask seal on them.
• M2.5×6.0B FLAT BIND screw x4
(Locktight)
NOTE: Be sure to apply the locktight to the screws instructed in the figure above.
3. Connect the LCD harness to the connector on the system board.
4. Arrange the wireless antenna cables along the guide (front) and secure them with
guide.
5. Pass the cables to the back of computer through the slot.
6. Install the keyboard and k/b cover of the system .
7. Arrange the wireless LAN antenna cables along the guide and contact with the
connector .
8. Secure the display assembly from the back of computer with the following screws.
• M2.5×6.0B FLAT BIND screw x4
(Locktight)
