5. DISPLAY
EO1-11110
5-4
It is recommended to prepare a copy of the above table, and place it near the register.
5.2. LOWER ROW (10-digit 7-segment Numeric Display)
(1) Numeric Display
AMOUNT (7 digits) Displays the numeric data, such as amount, quantity, etc.
When the amount is negative, the symbol “ - ” is displayed as well.
NOTE: When the following codes are being entered, the digits for “RPT” and “DPT” may be used as well
(all 10 digits). On exceeding the 10 digits, the lowest 10 digits are being displayed.
PLU Code (max. 13 digits as option)
Non-add Number (max. 18 digits)
Customer File No. (max. 12 digits)
DPT (2 digits) Displays the Department Code of the department item just entered. The department name is also displayed in
the Upper Row. It stays lit when repeating the same department item entry.
When a PLU is entered, PLU name is displayed in the Upper Row.
RPT (1 digit) Displays the repeat count of the same Department or PLU item. The count is indicated from the second entry
on, and only the lowest digit of the repeat count will be displayed even when the count exceeds nine (such as
“0” for 10, “1” for 11, etc.)
5.3. TRIANGULAR LAMPS
SIGN ON This lamp turns lit only when the Cashier Code Entry method is selected. It lights up when a cashier has signed ON or
signed IN. It goes out when the cashier has signed OFF or signed OUT, and the message “LOG” is displayed in the
Upper Row instead.
ALM Lights up with the alarm buzzer generated to indicate that the last operation or numeric entry was an error. To clear the
error status, depress the [C] key.
R OFF Lights up when the Receipt-OFF mode is declared by the [LOG/RECEIPT] (or [RECEIPT]) key. In this condition, no
receipts will be issued for a sale to be entered. It goes out by depressing the [LOG/RECEIPT] (or [RECEIPT]) key again
for Receipt-ON mode.
TL Lights up on a finalizing operation with the total amount displayed when the sale is finalized without any amount tendered.
ST Lights up when the [ST] key is depressed, indicating that the displayed amount is subtotal. The lamp is also illuminated
when the [TXBL TL] or [FSTL TEND] key is depressed, indicating that the displayed amount is the taxable total or food-
stampable total. It also lights up when the amount tendered is less than the sale total with the shortage amount (balance
due) is displayed.
CG When an amount tendering operation is performed, it lights up with the change due displayed.
5.4. STATUS LAMPS
SLIP Lights up when a validation slip is properly inserted to allow validation print. It flickers to require a validation when the
validation compulsory status has been programmed on the last operation. It also flickers to require an endorsement print
using the Remote Slip Printer or the Receipt/Journal Printer.
IN-LINE It is used when the ECR is used as an terminal in a Master-Satellite system. When the ECR is used as a stand-alone
machine, this lamp is not used.
5.2 LOWER ROW (10-digit 7-segment Numeric Display)
Error Message Cause of the Error
(Standard Setting)
E F T T I M E O U T Time-out condition on the EFT terminal
R E C E I P T R E Q U I R E D Entry of new sale transaction is attempted before issuing the store
receipt.
E F T C O M E R R O R Communication error between the ECR and the EFT terminal.
M I S C E R R O R Other errors
