6. DLL (Down-Line-Loading) OPERATIONS
EO1-11110
6-1
6. DLL (Down-Line-Loading) OPERATIONS
Submode DLL Job Remarks
No.
501 Store Name/Message, Commercial Message Programming
502 Cashier Code and Name Programming NOTE 1 below
504 PLU Table Programming
505 Time/Date Setting
508 Amount Limit Setting for Function Keys
520 Salesperson Code and Name Programming
525 Link PLU Table Programming
526 Tare Table and General Unit Weight Setting
527 PLU Preset-code Key Setting
531 Display Message Programming
535 Negative Amount Key Limit Amount Setting
540 PLU Price Dollar Discount/Extra Charge Amount Setting
569 Terminal Connection Table Setting
500 %+ and %- Preset Rate Setting
Preset Rate Setting for Selective Itemizers
Foreign Currency Exchange Rate Setting
Tax Table Programming
GTS Rate Setting
6. DLL (Down-Line-Loading) OPERATIONS
In an in-line system (Master-Satellite system), most programming data are set on the Master Terminal and down-
line-loaded (DLL) to Satellite Terminals. The DLL operations introduced in this chapter are pure DLLs, i.e. merely
loading the data programmed in the Master Terminal to Satellite Terminals. DLLs automatically performed with
programmed data changes are introduced in the next chapter (Chapter 6). If any other DLLs not introduced in this
and next chapters are required, ask your TOSHIBA TEC representative. Please also note that TERMINAL
DESIGNATION (see Chapter 2) can be operated prior to a specific DLL operation, to designate Satellite
Terminals that receive the DLL.
DLL JOB LIST
NOTE: DLL is possible only when the non-floating cashier feature is used.
