4. READ AND RESET REPORTS
EO1-11110
4-7
3) When individual department reading (daily/GT) is performed, press the [OPEN] key before
performing all department reading (daily/GT). Then, only the consolidated data is created to
output the process report.
4.2.2 IN-LINE REPORT PRINT FORMAT
IN-LINE REPORT TYPE
An in-line report can be classified into the following five types.
1. Collects data from each terminal to print a consolidation result:
All Salesperson, Credit Card Company Sales, Department Group, Hourly Range, All Department, All/Zone
PLU (Local File), and PLU Group Reports
2. Collects data from each terminal to print a collection result per terminal:
Indiv. Terminal All Cashier Report (Non-floating Cashier)
3. Collects data from each terminal to print a collection result per terminal and then print the consolidation
result:
Financial, Media Sales & In-drawer and All Media Sales Total & Cash-in-drawer Reports
4. Creates a process data using consolidated data and prints a report:
Indiv. Department, Department Gross Profit, Indiv. PLU, and Inactive PLU Reports
5. Prints data in the center file possessed by the master terminal:
Indiv./All Cashier (Floating Cashier), All/Zone PLU (Local File), and All/Indiv./Inactive/ Debit/Credit Customer
File Reports
The print format of each report is basically the same as the format of the corresponding standalone terminal
report except that some indications are additionally printed as in-line operation job IDs. The following is print
format example of the in-line report type 1 described above.
4.2 IN-LINE REPORTS
TEC STORE
1343 PEACH DRIVE
PHONE : 87-6437
Open 8:00am to 7:00pm
Closed: every Wednesday
19-12-1994 MON #111101
************************
#111101 0001Z
#222202 0001Z
#999909 0001Z
************************
#555505 ∆∆∆∆
#666606 ∆∆∆∆
0147 19:27TM
- - -
RTR Symbol
Report Name (When designating a zone, a zone range is printed.)
For print items,refer to the similar report described in the Stand-
alone section.
Register No., Reset Count
(on Reset Report only)
RTR Symbol
Unfinished register No.and status
?: No response
BUSY: The terminal is busy.
Blank: Other statuses
NO
D: No consolidation data exists.
NO
A: Discord of consolidation data.
Consecutive No., Current Time
Only for the CVS spec.
