Setup Pages
58
MVP Modero ViewPoint Touch Panels
WAV files - Supported sample rates
The following sample rates for WAV files are supported by MVP-8400 panels:
Volume Page (Cont.)
Master Volume: This section allows you to alter the current master volume level:
• Use the UP/DN buttons to adjust the volume level (range = 0 - 100).
• The Master Volume bargraph indicates the current volume level.
• The Mute button toggles the Mute feature.
Default Panel Sounds: • Activating the Button Hit button plays a default sound when you touch an
active button.
• Activating the Button Miss button plays a default sound when you touch a
non-active button or any area outside of the active button
• The Play Test Sound button plays a test WAV/MP3 file over the panel’s
internal speakers.
Internal Sound Level: Adjusts the volume level on the panel’s internal speaker:
• Use the UP/DN buttons to adjust the volume (range = 0 - 100)
• The Internal Sound Level bargraph indicates the current sound level
• The Mute button mutes the internal speaker volume
Intercom Mic Level: Adjusts the volume level on the panel’s microphone
• Use the UP/DN buttons to adjust the microphone level (range = 0 - 100)
• The Mic Out Level bargraph indicates the current Mic Out level
Intercom Sound Level: Sets the volume level for intercom calls (from another MVP-8400)
• Use the UP/DN buttons to adjust the Line-In volume level (range = 0 - 100)
• The Line-In Level bargraph indicates the current Line-In level
• The Mute button mutes the Line-In volume
Supported WAV Sample Rates
• 48000 Hz • 16000 Hz
• 44100 Hz • 12000 Hz
• 32000 Hz • 11025 Hz
• 24000 Hz • 8000 Hz
• 22050 Hz
