Setup Pages
83
MVP Modero ViewPoint Touch Panels
Refer to the EAP Authentication section on page 155 for further details on these security
options.
Refer to the Using the Site Survey tool section on page 22 for more information on using this
feature.
Client certificate configuration
There are several ways in which a client certificate can be configured by an IT department. The client
certificate and private key can both be incorporated into one file or split into two separate files. In
addition, the file format used by these files could be PEM, DER, or PKCS12. These formats are
described later in this section. The following table describes how to fill in the fields for each possible
case.
EAP-TLS Settings (Cont.)
Certificate Authority: When pressed, the panel displays an on-screen Certificate Authority (CA)
File Location keyboard which allows you to enter the name of the certificate
authority file which is used to validate the server certificate.
This field is optional.
If a server certificate is used, it should first be downloaded into the panel and
the Certificate Authority field should then be set to the name of that certificate
file. No file path should be used for this setting as all certificates are stored in
a specific directory that the user cannot control or change.
• Use the on-screen keyboard’s Clear button to completely erase any
previously stored network path information.
Client Certificate: Opens an on-screen keyboard. Enter the name of the file containing the client
(panel) certificate for use in certifying the identity of the client (panel).
• Refer to the Client certificate configuration section for information regarding
Client Certificates and their parameters.
Private Key: When pressed, the panel displays an on-screen Client Private Key File Loca-
tion keyboard which allows you to enter the name of the file containing the
private key.
• Use the on-screen keyboard’s Clear button to completely erase any
previously stored network path information.
Private Key password: This field should only be used if the Private Key is protected with a password.
If there is no password protection associated with the Private Key, then this
field should be left blank.
• When pressed, the panel displays an on-screen Private Key Password
keyboard which allows you to enter an alpha-numeric password string.
• Use the on-screen keyboard’s Clear button to completely erase any
previously stored network path information.
Save/Cancel: • Save - store the new security information, apply changes, and return to the
previous page.
• Cancel - discard changes and return to the previous page.
Client Certificate Configuration
Certificate Configuration Client Certificate Field Private Key Field
Single file contains both the client certificate and
the private key. Format is: PEM or DER.
Enter the file name Enter the same file name
First file contains the client certificate, second file
contains the private key. Format is: PEM or DER.
Enter the first file name Enter the second file name
Single file contains both the client certificate and
the private key. Format is: PKCS12
Leave this field blank Enter the file name
First file contains the client certificate, second file
contains the private key. Format is: PKCS12
not supported not supported
