MVP-8400i Modero Viewpoint Wireless Touch Panels
Protected Setup Navigation Buttons
The Protected Setup Navigation Buttons (FIG. 53) appear on the left of the panel screen when the
Protected Setup page is currently active.
Protected Setup Page (Cont.)
Options: • Function Show - toggles the display of the channel port, channel code, level
port and level code on all touch panel buttons (see
FIG. 52).
• Page Tracking - toggles the page tracking function. When enabled, the panel
reports page data to the NetLinx Master.
• Telnet - enables/disables the panel’s telnet server (to allow direct telnet
communication to the panel).
• Front Button Setup Access - activates the two lower buttons on the front of
the panel for accessing the Setup and Calibration pages (see
FIG. 42 on
page 51). The default setting is On.
- Press and hold these buttons for 3 seconds to access the Setup page.
- Press and hold these buttons for 6 seconds to access the Calibration page.
System Recovery: • Reset System Settings - deletes all of the current configuration parameters
on the panel (including IP Addresses, Device Number assignments,
Passwords, and other presets). This option invokes a Confirmation dialog,
prompting you to confirm your selection before resetting the panel.
System Recovery (Cont.): • Remove User Pages - allows you remove all TPD4 touch panel pages
currently on the panel, including the pre-installed AMX Demo pages. This
option invokes a Confirmation dialog, prompting you to confirm your selection
before removing the panel pages.
Note that the YES button on the Confirmation dialog is disabled for 5 seconds
as additional protection against accidentally resetting the panel or removing
the panel pages.
Reboot Panel: Pressing this button causes the panel to reboot after saving any changes.
Docking Station: • Dock Status - illuminates when the MVP is docked and communicating with
the Docking Station.
• Undock Panel - forces the docking station to release the MVP without
requiring a User Access username or password.
• Disable Docking Station LED - disables the display of the LEDs on the
docking station.
FIG. 52 Function Show example
Channel Code
3,132
2,8 3,50
Channel Port
Level Port
Address Port
Address Code
Channel Code
BUTTON
