Chapter 5 Parts Lists
CL-S700/CL-S703 5-16
PARTS LIST for CL-S700/CL-S703 TITLE: Unit, Frame U Sheet No. 1/2
Drawing No. 3 Rev. No. 0
Location Part Name Part No.
Q'ty/
Unit
Remarks @
3-1 Idle Gear A Sub Assembly JE99683-0 2 23205720
3-2 Idle Gear B Sub Assembly JE99684-0 1 23205730
3-3 Gear Plate Spring JE99651-0 1 21903240
3-4 SA, Gear Plate JN29715-0 1
3-5 SA, Frame U JN44706-0 1
3-6 SA, Head Cable JN67707-0 1
3-7 Wire Tie C6701-101# 1
3-8 Spring, Head L JN13603-0 1
3-9 Head Balance Seal JE99434-0 1 25201200
3-10 Sheet, Cover Cable JN54908-0 1
3-11 Head Earth Plate JE99117-0 1 20803381
3-12 Head Plate JE99011-0 1 20803370
3-13 Offset Spring JE99016-0 1 21902562
3-14 Slider JE99048-0 1 25200861
3-15 Spring, Head R JN13602-0 1
3-16 Curved Washer JE99065-0 1 90500390
3-17 Adjust Screw JE99192-0 1 92100202
3-18 Open Lever Spring JE99019-0 1 21902601
3-19 Lever, Head Up JN14201-0 1
3-20 Polyslider Washer JE99064-0 1 90500380
