Chapter 5 Parts Lists
5-37 CL-S700/CL-S703
PARTS LIST for CL-S700/CL-S703 TITLE: Unit, Frame Sheet No. 2/3
Drawing No. 9 Rev. No. 1
Location Part Name Part No.
Q'ty/
Unit
Remarks @
9-21 SA, Option Cable 1 JN67715-0 1
9-22 SA, Option Cable 2 JN67716-0 1
9-23 Bushing, Motor Drive JN22011-0 1
9-24 Pulley, Drive Shaft JN20302-0 1
9-25 Screw, HSS (KCP), M3.0x5 E30130-050F 2
9-26 Tension Pulley JE99154-0 1 2400090
9-27 Tensioner Pin JE99136-0 1 22601891
9-28 Plate, Tension JN24110-0 1
9-29 Tension Spring JE99131-0 1 21902722
9-30 SA, PF MTR Cable JN67705-0 1
9-31 Screw, PH, M3.0x6 E00130-060F 2
9-32 Screw, PH (SW+PW), M3.0x5 E04030-050F 3
9-33 Screw, PH (SW+PW), M3.0x6 E04030-060F 10
9-34 Screw, BH, M3.0x5K E00530-050KF 1
9-35 Screw, No.0, FHT (BT#1), M2.0x8 E13220-080F 1
9-36 E-Ring, 3.0 E60330-000F 2
9-37 E-Ring, 2.0 E60320-000F 1
9-38-1 Unit, Motor JN25801-0 1 For CL-S700/CL-S703 (Rev. No.1)
9-38-2 Unit, Motor JN25803-0 1 For CL-S700R (Rev. No.1)
9-39 Gear, One-way JN20201-0 1 (Rev. No.1)
