Chapter 5 Parts Lists
CL-S700R 5-60
PARTS LIST for CL-S700R TITLE: General Assembly Sheet No. 1/3
Drawing No. 1 Rev. No. 0
Location Part Name Part No.
Q'ty/
Unit
Remarks
Dedicated for
CL-S700R
1-1 Roll Holder JE99090-0 1 24600730
1-2 Flange, Paper Wide JM79201-0 1
1-3 Unit, Top Cover ---- 1 Ref: Drawing No. 10 / CL-S700, S703
1-4 Cover, Hinge JN56209-0 2
1-5 Holder, Paper Shaft Left JN56116-0 1
1-6 SA, Cover Inner Power JN56704-0 1
1-7 SA, Ribbon Holder JM34710-1 2
1-8 Stopper, Hinge JN54103-0 2
1-9 SA, Hinge JN59905-0 2
1-10 Unit, Mechanism JN99801-0 1 Ref: Drawing No. 2 / CL-S700, S703
1-11 Cover, Inner Paper JN56112-0 1
1-12 Unit, PCB - 1 Ref.: Drawing No. 14 / CL-S700, S703
1-13 Sheet 1, Power Protect JN54910-0 1
1-14 Plate, Power JN64101-0 1
1-15 Unit, Power Supply JN66801-0 1
1-16 Cover, Cable JN56201-0 1
1-17 SA, Power Cable JN67706-0 1
1-18 Cable, Ope-pane FFC JN67901-0 1
1-19 WS-2NS (Cable, Clamp) JN59903-0 3
1-20 SA, Fan JN65901-0 1
